SSR-40 DA Solid State Relay Module 40A 24V-380V for PID Temperature Controller 3-32V DC To AC

Features:
40A Solid State Relay for PID Temperature Controller.
Long service life and high reliability.
Highly reliable, compact size designed to offer users maximum simplicity.
Fast switching.
Reduced electromagnetic interference.
Specifications:
Control mode: DC-AC
Loading current: 40A
Loading voltage: 24 - 380V AC
Control voltage: : 3 - 32V DC
Control current: 3-25mA DC
On voltage: ≤1.5V AC
One-off Time: ≤10ms
Off leakage Current: ≤2mA
Dielectrics voltage-resistance: 2500VAC
Insulation resistance: 500MΩ/500VDC
Installation method: Bolt fixation
Environment temperature: -30°C-+75°C
Working indicator: LED
Color: White
Item size: 60 * 45 * 23mm / 2.4 * 1.8 * 0.9in
Net weight: 97g / 3.35oz
Package size: 60 * 45 * 23mm / 2.4 * 1.8 * 0.9in
Package weight: 97g / 3.35oz
Package List:
1 * SSR-40 DA Solid State Relay
