20x optical zoom 4pcs/lot waterproof auto track infrared outdoor security camera dome

SKU:

CK10404

Category: Dome Camera

$535.00

Enquiry

Footer Group

Description

Audio alram function optional, but this price is no Audio alram function, if nee audio and alram function, pls contract us.

waterproof auto track infrared outdoor security camera dome

Specifications

1080P 2MP IP IR PTZ Camera

1. 20X zoom
2. 150m IR range
3. WDR/ DNR(2D&3D)
4. 1/2.7" CMOS

Feature

High Quality 2 megapixel 20x Speed Dome Panasonic outdoor security cam

1/2.7" Exmor CMOS Sensor ,WDR,DNR(2D &3D)
20x zoom, 12digital zoom
2MP high resolution

150m IR Range,IP66 Rating

Specification

Model	IMP-RH6116-IR-Z
Image Sensor	1/2.7" Exmor CMOS
Effective Pixels	1920(H)x1080(V)
Minimum Illumination	Color: 0.5Lux F1.6, B/W: 0.02Lux F1.6
White Balance	Auto / Manual / One Touch WB / ATW
Min. Illumination	Color: 0.05Lux (F1.6, AGC ON), B/W: 0.005Lux (F1.6, AGC On); 0 Lux with IR
White Balance	Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp
AGC	Auto/Manual
S/N Ratio	>50dB
Day & Night	IR Cut Filter
Digital Noise Reduction	3D DNR
Wide Dynamic Range	Digital WDR
Shutter Speed	50Hz: 1~1/30,000s; 60Hz: 1~1/30,000s
Focus Mode	Auto/Semiautomatic/Manual
Enhancement	Smart Defog: on/off
Focal Length	4.7 ~ 94mm, 20x
Zoom Speed	Approx 2.7s(Optical Wide-Tele)
Angle of View	58.3 ~ 3.2 degree (Wide-Tele)
Min. Working Distance	10 ~ 1,500mm (Wide-Tele)
Aperture Range	F1.6 ~ F3.5
IR Distance	150M
Day& Night	ICR
Auto Focus	Auto / Semi-automatic / Manual
Ethernet	10Base -T, /100Base-TX, RJ45 Connector
Max.Image Resolution	1920×1080
Frame Rate	50Hz:25fps( 1920×1080P),25fps((1280×720P) 60Hz:30fps( 1920×1080P),30fps((1280×720P)
Image Compression	H.264

Protocols	TCP/IP, HTTP, DHCP, DNS, RTP/RTCP, RTSP, PPPoE, SMTP, NTP (FTP, SNMP optional)
No. of Users	Up to 6 user
Dual Stream	Support
User/Host Level	3 Levels: Administrator, Camera control, Live view online
Protocols	IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE
Simultaneous Live View	Up to 10
Streams	Three Streams

User/Host Level	Up to 32 users, 3 Levels: Administrator, Camera control, Live view only
Application programming	Open-ended API, support Onvif, PSIA and CGI
Camera Control	Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode
Client software	Support iVMS-4200 PCNVR
Web Browser	IE 7, IE 8, IE 9, Chrome 8+, Firefox 3.5+, Safari 5+, support multi-language
Auto tracking	support
Security Measures	User authentication (ID and PW), host authentication (MAC address)
Pan Range	360° endless
Pan Speed	High Speed: 0.01° ~ 200° /s Low Speed: 0.01° ~ 35° /s
Tilt Range	-5° ~ 92° (auto flip )
Tilt Speed	High Speed: 0.01° ~ 120° /s Low Speed: 0.01° ~ 35° /s
Pan preset speed	High Speed: 250° /s Low Speed: 35° /s
Number of Preset	255
Pattern	4 patterns, with the recording time not less than 10 min per pattern
3D Position	Yes
Proportional Zoom	Rotation speed can be adjusted automatically according to zoom multiples
Working Temperature/ Humidity	-40°C ~ 75°C (-22° F ~ 149° F), 90% or less
Protection Level	IP66 with TVS 4000V lightning protection, surge protection and voltage transient protection
Power Supply	DC12V±10% (AC24V±10% optional)
Power Consumption	40W MAX
Color / Material	White / Aluminum
Net Weight(approx.)	8.0Kg (8.8Ibs)
