Model No .

NH4RL130 //NH4RS-130 //NH4RP-130

Signal model

PAL/NTSC

Image sensor

1/2.8" SONY CMOS

Effective pixel

1280*960

Horizontal resolution

960P

Minimum illumination

Color to B/W,Color:0.1Lux,B/W:0.01Lux

S/N ratio

>60dB(Enhanced)

Backlight compensation

On/Off

White balance

Auto

Electronic shutter

PAL:1/25~1/100000s NTSC:1/30~1/100000s

Focus length

3.9-39mm

Optical focus

10X

Focus

Auto / Manual / Push Auto , the use of high-performanceDSP

to realize complete digit and ultra-high speed focus function

Presets

256

IR distance

35m

Patrol track

4groups, each can record 200 actions

Cruise track

Total 30 presets can join cruise, can setting the

presets\\\' residence time

Other scan

Support Horizontal scan, deuce area scan, scan random

Rotation range

Horizontal 360°unlimted rotation, Vertical 90°,auto reversal

Rotation speed

Horizontal & Vertical Min 0.01°,Max 200°/S

Video compression

H.264 Main Profile encoding ;

MJPEG / JPEG Baseline encoding

Audio compression

G.711, G.726, support 32K stereo

Primary stream

1280 * 960 , 25fps

Secondary stream

640 * 480 , 25fps

Video bit rate

32Kbps-16Mbps continuously adjustable,

support CBR / VBR

Network protocol

TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,

DDNS,DHCP,FTP,NTP,PPPOE,SMTP,UPNP

ONVIF support

Support

Power supply

DC12V/3A

Work environment

-20°C~+50°C (select temperature control accessories), <95%RH
