Product Category:

Portable AP/Repeater

Model Name:

CF-WR150N

Support Computer Systems:

Windows 98SE, Windows7, Me, 2000, XP, Vista, MAC,Linux etc.

Connecting port:

RJ45 LAN port

Transmission Rate:

11n: Up to 150Mbps (dynamic)
11g: Up to 54Mbps (dynamic)
11b: Up to 11Mbps (dynamic)

Outside Color:

Black

Support WLAN Standards:

IEEE802.11n, IEEE802.11g, IEEE802.11b, IEEE802.3, IEEE802.3u

Modulation Mode:

DBPSK, DQPSK, CCK, OPDM,16-QAM, 64QAM

RF output power:

15-17dBm(Power can be adjusted)

Antenna:

2 dBi PCB Antenna

Input power:

100V-240V AC

Plug type:

EU standard plug (USA standard ,please note )

Frequency Range:

2.4-2.4835 GHz

Product size:

75mm*55mm*24.5mm

Color box package size:

135mm*105mm*75mm

Unit product weight:

0.24 KG

Standard carton box gross weight:

26 KG

Standard carton box size:

560mm*540mm*420mm (100 pcs/carton)

Certification:

CE, FCC, CCC, ISO9001

Theoretical Range Distance:

25-50m (indoor)

Operating temperature:

0 to 40 Celsius degree

Storage temperature:

-40 to 70 Celsius degree

Relative humidity:

5% to 90%RH (non-condensing)

Response Rate:

150M: -68dBm@10%PER
130M: -68dBm@10%PER
108M: -68dBm@10%PER
54M: -68dBm@10%PER
11M: -68dBm@10%PER
6M: -68dBm@10%PER
1M: -68dBm@10%PER

Packing List:

150M portable AP/Repeater x1
1M web line x1
Quick installation guide x1
Guarantee card x1
