VGA OV7670 CMOS Camera Module Lens 640*480 SCCB Compatible W/I2C Interface for Arduino

Features:
High sensitivity for low-light operation.
Low operating voltage for embedded application.
Standard SCCB interface compatible with I2C interface;
Raw RGB, RGB (GRB4:2:2, GB565/555/444),YUV(4:2:2) and; YCbCr(4:2:2)output format.
Support VGA, CIF and from CIF to 40 * 30 format.
Vario Pixel method for sub-sampling.
Auto Image Control: AEC, AGC, AWB, ABF, ABLC.
Image Quality Control: Color saturation, hue, gamma, harpness and anti-blooming.
ISP includes noise reduction and defect correction.
Support image scaling; Lens shading correction.
Flicker 50/60Hz auto detection.
Color saturation level auto adjust.
Edge enhancement level auto adjust.
De-noise level auto adjust.
Specifications:
Photosensitive Array: 640 *480
IO Voltage: 2.5V to 3.0V
Operating Power: 60mW/15fpsVGAYUV
Sleeping Mode: <20μA
Operating Temperature: -30 to 70 deg C.
Output Format: YUV/YCbCr4:2:2 RGB565/555/444 GRB4:2:2 Raw RGB Data (8 digit)
Lens Size: 1/6"
Vision Angle: 25 degree
Max. Frame Rate: 30fps VGA
Sensitivity: 1.3V / (Lux-sec)
Signal to Noise Ratio: 46 dB
DynamicRange: 52 dB
Browse Mode: By row
Electronic Exposure: 1 to 510 row
Pixel Coverage: 3.6μm * 3.6μm
Duck Current: 12 mV/s at 60°C
Product Weight:12g / 0.41oz
Product Size: 3.3 * 3.5 * 3.2cm / 1.3 * 1.3 * 1.2in
Package Weight: 12g / 0.41oz
Package Size: 9.3 * 8.2 * 3.2cm / 3.6 * 3.2 * 1.2in
Package List:
1 * VGA OV7670 CMOS Camera Module Lens CMOS 640X480 SCCB W/ I2C Interface for Arduino
