Onvif 1920*1080P HD 1.0MP Mini Dome IP Camera IR Night Vision P2P Plug Play CCTV Security Camara,Free Phone view Free shipping

1. This module uses Huawei Hass Hi3518E + OV9712 (38 or 32) as the core,High Resolutiion 1.0 Megapixel 1/4" CMOS Sensor

2. 1280*720P Resolution 25fps real time.

3. Using XM CMS client, Supports P2P remote, does not need to open router ports without port mapping, Easy remote access.

4. Support IE, Firefox,Google browser

5. Supports mobile phone remote access easily, AS: Apple, Android, Win, Symbian, Blackberry.

6. Support for international Onvif agreement, compatible XM,Hikvision, Dahua and other well-known manufacturers of NVR.

7. 24IR LED With 20m IR Distance

8. Built in IR-CUT Filter

9.Day & Night Vision

10. High Quality ABS Plastic

 Model NO.                                                          SAE50-NX3C200A

amera

Image Device                                                       1/4" High Sensitivity CMOS

Image senser                                                       OV 9712

DSP                                                                         HI3518E

TV System                                                              PAL/NTSC

Effective Pixels                                                      1280(H) x 720(V)

Min. Illumination                                                    0Lux(IR-ON )

Day/Night                                                                ICR

Infrared LED                                                           24pcs Taiwan Dingyuan IR LED

IR Distance                                                            15-20 Meters

Infrared Spectrum                                                 850nm

Lens

Focal Length                                                         (Default:3.6mm)6mm/8mm Optional

Compression

Video compression                                             H.264 Main Profile/JPEG capture

Video Bite Rate                                                    100Kbps~6Mbps

Audio compression                                             G.711a


Max Resolution                                                    1280(H) x 720(V)

Frame Rate                                                           PAL50Hz:25fps (1280*720);NTSC60Hz:30fps (1280*720);

 Image settings                                                  Saturation, Brightness, Contrast adjustable  through Client software or web server

Network Function

Storage                                                                  Network storage

Intelliget Alarm                                                  Motion detect, video loss ,network disconnection, IP address conflict, storage full, storage error

Protocol                                                                 TCP/IP,HTTP,DHCP,DNS,DDNS, PPPoE, SMTP,NTP

                                                                                (HTTPS,SIP ,802.1x,IPv6 optional)

Basic                                                                      Anti-flicker, dual stream, heartbeat, password protection

Interface

Communication Interface                                  1 RJ45 10M/100M self-adaptive Ethernet interface

Video output                                                      1Vp-p Composite Output(75Ω/BNC)

General

Operating condition                                             -10~60,umidity 90% less (non-condensing)

Power supply                                                        DC12V±10%

Current                                                                   <280mA

Dimensions                                                          100*100*90mm

Net Weight                                                            250g/pcs
