The performance of this model could even better than the performance of benchtop oscilloscope. It has 4 independent analog channels, 1GSa/s real-time sampling rate, 2mV-10V/DIV input sensitivity, and 250MHz bandwidth. It is powered by USB2.0 Interface, plug and play device with small size which is easy for carrying. High cost performance, pass/fail test, resourceful trigger function, dynamic cursor tracking, waveform record and replay function.
Features:
The performance of this model could even better than the performance of benchtop oscilloscope. It has 4 independent analog channels, 1GSa/s real-time sampling rate, 2mV-10V/DIV input sensitivity, and 250MHz bandwidth.
Pass/fail test, resourceful trigger function, dynamic cursor tracking, waveform record and replay function. The operation interface is similar to banchtop oscilloscope, easy to operate with high cost performance.
USB2.0 Interface, plug and play device.
Good mechanical design with small size which is easy for carrying. The outer case is made by the same material with iPad - Anodised aluminium. It has great heat resistance and abrasive resistance with beautiful appearance. The hardness of aluminium alloy surface is greatly improved.
Fit for the portable computers, table PC, and repairing/fixing of production line. Suitable for business trip use.
Software support: for Windows10, Windows 8, Windows 7.
The waveform data could be output to EXCEL,BMP,JPG as time and voltage category.
More than 20 kinds of automatic measurement function, PASS/FAIL Check function, fit for engineering application.
Waveform averaging, afterglow, lightness control, reverse, add, subtract, multiply, divide, X-Y display.
FFT spectrum analyzer.
One computer could connect with multiple oscilloscopes, expand the channel number easily.
USBXI standard interface, easy to insert into USBXI case to constitute assembling instrument.
Provide secondary development library DLL; Provide Labview\\VB\\VC\\QT developing examples.
Specifications:
Brand: Hantek
Model: Hantek6074BC
Channel: 4 Isolated Channels
Bandwidth: 70MHz
Input Sensitivity: 2mV/div~10V/div
Sampling Rate: 1GSa/s
Material: Metal + Plastic
Oscilloscope Probe Model: PP-90
Item Size: Approx. 210 * 125 * 37mm / 8.3 * 4.9 * 1.5in
Item Weight: Approx. 457.3g / 16.1oz
Package Size: Approx. 25 * 18.5 * 11cm / 9.8 * 7.3 * 4.3in
Package Weight: Approx. 1136.6g / 40.1oz
Hardware Specifications:

Note:
Hantek 6074BC Oscilloscope is for 3 years Warranty!
Please read the instruction manual data CD carefully to avoid injury and prevent damage to this product.
Package List:
1 * USB Digital Storage Oscilloscope
2 * Dolphin/Gator Clip Cable
2 * Oscilloscope Probes
1 * USB Power Line
1 * Upper-computer Software CD with User Manual
