Digital Temperature Controller 0-400 Degrees PIDThermocouple thermostat Temperature diagnostic-tool Heat-reset Alarm function

PID Digital Temperature Control Controller Thermocouple 0 to 400°CMeasuring accuracy: ±0.5%FS
Cold-end compensation tolerance: ±2°C(can be modified by software for 0~50°C)
Resolution: 14 bit
Sampling cycle: 0.5 SecProcess value (PV), Setting value (SV)
Output, alarm and self-tuning can be indicated by LEDPIN control (including ON/OFF, step-type PID and continuous PID)
Alarm function output: 1 way
Contact capacity of output: 250V AC 3A (resistive load)
Setting value (SV): identical to measuring range (PV)
Proportional band (P): 0~full range (ON/OFF control when set to 0)
Integral time (I): 0~3600 sec (No integral action when set to 0)
Derivative time (D): 0~3600 sec (No derivative action when set to 0)
Heat-reset proportional cycle: 1~100 secDetective temperature range:0 to 400°C
Insulation resistance: >50M ohm(500V DC)
Insulation resistance: 1500V AC/min
Power Consumption: <10 VA
Service environment: 0~50°C,
environment with no corrosive gas 30~85% RHDimensions:5.5 * 6.3 * 11.5 cm / 2.2 * 2.5 * 4.5in
Weight: 219g / 7.72ozPlease assure that you are familiar with this product before you buy, because the manual we offer is Chinese.Package Includes:
1 * Temperature Control Controller
1 * Instruction Manual
