Product Specifications of Wireless Router

Chipset:

MTK7620A

Support Computer Systems:

Windows 98SE, Windows7, Me, 2000, XP, Vista, MAC,Linux etc.

Connecting port:

1 RJ45 LAN port

Transmission Rate:

11n: Up to 300Mbps (dynamic); 11g: Up to 54Mbps (dynamic)

Outside Color:

11g: Up to 54Mbps (dynamic)

Support WLAN Standards:

Black

IEEE802.11n, IEEE802.11g, IEEE802.11b, IEEE802.3, IEEE802.3u

Modulation Mode:

DBPSK, DQPSK, CCK, OPDM,16-QAM, 64QAM

RF output power:

20-24dBm(Power can be adjusted)

Antenna:

Smart internal 5 dBi Antenna x 2

Input power:

100V-240V AC

Plug type:

US standard plug / EU standard plug detachable (other standard plug can be customized)

Frequency Range:

2.4-2.4835 GHz

Certification:

CE, FCC, CCC, ISO9001

Theoretical Range Distance:

25-50m (indoor)

Encryption:

WEP/WPA/WPA2/WPA-PSK/WPA2-PSK & WPS

Voltage Input:

220V direct plug

Size:

109mm*65mm*60mm (EU plug);109mm*65mm*41.5mm (US plug)

Operating temprerature:

0 to 40 Celsius degree

Storage temperature:

-40 to 70 Celsius degree

Relative humidity:

5% to 90%RH (non-condensing)

Response Rate:

150M: -68dBm@10%PER; 130M: -68dBm@10%PER

Packing List:

108M: -68dBm@10%PER;54M: -68dBm@10%PER

11M: -68dBm@10%PER;6M: -68dBm@10%PER

1M: -68dBm@10%PER

300M portable AP/Repeater x1

1M web line x1

Quick installation guide x1

Guarantee card x1
