720P HD 1.0MP Wireless Wifi IR Network IP camera P2P ONVIF Outdoor onvif IR CUT

SKU:

CK10325

Category: IP Camera

$49.90

Enquiry

Footer Group

Description

720P HD 1.0MP Wireless Wifi IR Network IP camera P2P ONVIF Outdoor onvif IR CUT

New 1.0MP Wireless IP Camera In Big Promotion

Mini 720P 1.0MP Wireless WiFi IP Camera VideoSurveillance Waterproof Bullet Cam

1. WiFi Module Built-in

2. New High Performance Multi-media DualCore Hi3516C Processor

3. 720P (1280*720) Sony MX222 1/2.7 InchCMOS Sensor

4. Built in P2P Function, Remotely View& Control IPC No Need DDNS

5. Embedded Linux, support Onvif

6. With IR Cut, Auto Day and Night

6. 3.6mm HD MTV Lens

8. 24pcs of 5mm IR LED, 20M IR Distance,With IR-Cut

9. H.264 Video Compression, Support Dual Stream

10. Transmission Up To 1080P30fps

11. Support Iphone, Android, Ipad SmartPhone

12. Support IE, Chrome, Firefox, SafariBrowser

13. with Free CMS Software for Computer

14. Support RTSP, FTP, PPPOE, UPnP, TCP/IP,HTTP, TCP, SMTP, FTP, DHCP, DNS, DDNS, NTP Protocols

Specification
Model No.
DT-20AB21R-WiFi
CMOS
Device
720P Sony MX222 CMOS Sensor
Size
1/2.7 Inch
Effective Pixels
1.0MP (1280*72030fps)
Min. Illumination
Color
0.01LUX (Color)
B/W
0LUX
IR Sensitivity
Yes
IR Cut
Yes, Auto Day & Night
IR Distance
36pcs of 5mm IR LED, 20M IR Distance
Lens
Lens
3.6
Aperture
Fixed Aperture
System
Embodied Linux System
Video
Compression
H.264
Picture Resolution
Main Flow: 1920*108030fps
Sub Stream: D1 704*57630fps
Steam Flow
Support Dual Stream
Bit Rate
0.1-6MB/S
Bit Rate Type
CBR/VBR
BLC
Auto
AGC
Auto
White Balance
Auto
S/N Ratio
>50 DB
Brightness
Adjustable
Contrast
Adjustable
Saturation
Adjustable
Subtitles Input
Support Channel Name, Date/Time
Flip Configure
Up/Down, Left/Right
Audio
Audio Input/ Output
One Channel Audio Input, One ChannelAudio Output (Optional)
Compression
G.711
Equipment
An External Audio Equipment
Two Way Audio
Support the Microphone Input and LineOut, Support Two-Way Voice Intercom Equipment (Optional )
Alarm
Alarm I/O
1 Channel Input/output (Optional)
Motion Detection
Yes
Privacy Mask
Yes
FTP
Yes

Optional Function
TF Card Slot
No
POE
No
WiFi
Built-in
P2P
Support
RS485
No
Bracket
Included
Network
Ethernet
Ethernet (10/100 Base-T), RJ-45 Connector
Safety
IP Address Filter, User Level Password Protection,User Access Log
Protocol
HTTP, TCP/IP, UDP, SMTP, DDNS, DNS, SNTP,DHCP, FTP, RTP, RTSP, UPNP, ONVIF, 28181
Software
Web Browser
Support Internet Explorer, Firefox,Chrome, Safari
Management Software
CMS and The Devices Compatible with Onvif
Mobile Phone
Support Iphone, Android, Blackberry,Symbian, Windows Mobile
Remote
Support DDNS, P2P
Operating
Temperature
-20°-60°C
Humidity
-10-85%
Working Environment
Indoor & Outdoor
Power Consumption
DC 12V, 1A
Certification
CE, RoHs, FCC
Packing Lists
1 X IP Camera
1 X CD
1 X screw Bags
1X Power Supply Adapter
The appearance might be different with the attached picture. The pictureis only for your reference, especially for power supply and color boxappearance.
