50MHz Crystal Oscillator Frequency Counter Tester DIY frequency meter cymometer Kit 5 Digits Resolution digital frecuencimetro
This frequency counter DIY kit is easy to install and debug. Its frequency range is 1Hz-50MHz.Features:Designed to measure the oscillation frequency of most crystal oscillators.Based on PIC microcontroller, can measure frequency from 1Hz to 50MHz.Five digits accuracy, for example: x.xxxx kHz, x.xxxx MHz, or xx.xxx MHz.Optional power-saving mode: can automatically turns the display off if the frequency didn't change significantly within 15 seconds.General USB interface can be used for power supply, external power supply or 9V battery also can be used.Very low component count: a PIC 16F628, 5 7-segment LED displays, a 20-MHz crystal and a few resistors.Simple construction, compact design, easy to install and debug.Installation Detail:https://www.dropbox.com/s/itazxn00oe5uxbl/E0330.pdf?dl=0Note:Pictures of testing process are just for reference, please in kind prevail!Specifications:Material: PCBColor: RedFrequency Range: 1Hz-50MHzCrystal Test Range: about 4MHz-48MHzAssembled Item Size: 8 * 5.5 * 0.7cm / 3.2 * 2.2 * 0.3inPackage Size: 12.5 * 9 * 2cm / 4.9 * 3.5 * 0.8inPackage Weight: 34g / 1.2ozPackage List:1 * Frequency Counter
