Image Device

1/3 Inch Sony CCD Nextchip 2150

Picture Elements

NTSC:1178 x 794,PAL: 1260 x 782

Resolution

1200TVL

Min. Illumination

0.1 Lux / F1.2

S/N Ratio

More than 48dB

Electronic Shutter

1/50(60) to 1/100,000

White Balance

Auto

DWDR

on/ off

2D NR

on/ off

AGC

Auto

Color/Black and White

auto/color/black and white/external trigger

BLC

on/ off

Privacy Mask

on/ off (8 setting areas)

Sync. System

Internal synchronism

Video Output

1 Vp-p / 75 Ohm

Power Requirements

DC 12V ±10%

Power Consumption

2A

Operating Temp.

-20C to +50C ( 2F to 122F )

Operating Humidity

20 to 80 %

Storage Temp.

-40C to +60C ( -40F to 140F )

Storage Humidity

20 to 95 %
